Quick Overview
Overhead Stirrer Impeller BR 13 Square-Blade
Due to its blade dimensions, the square-blade impeller BR 13 is ideal for loosening and homogenizing in vessels with the following characteristics:
ideal vessel diameter: 140 mm
ideal ground clearance: 7 mm
ideal filling level: 140 mm
ideal volume: 2,200 ml
• Recommended for applications which require average speed
• For mixing tasks with little or average viscosity
• Blade size, 70 x 70mm
• Material – stainless steel
• Length – 450mm
• Shaft diameter – 8mm
• Max rpm – 800
Due to its blade dimensions, the square-blade impeller BR 13 is ideal for loosening and homogenizing in vessels with the following characteristics:
ideal vessel diameter: 140 mm
ideal ground clearance: 7 mm
ideal filling level: 140 mm
ideal volume: 2,200 ml
• Recommended for applications which require average speed
• For mixing tasks with little or average viscosity
• Blade size, 70 x 70mm
• Material – stainless steel
• Length – 450mm
• Shaft diameter – 8mm
• Max rpm – 800
Details
Overhead Stirrer Impeller BR 13 Square-Blade
Due to its blade dimensions, the square-blade impeller BR 13 is ideal for loosening and homogenizing in vessels with the following characteristics:
ideal vessel diameter: 140 mm ideal ground clearance: 7 mm ideal filling level: 140 mm ideal volume: 2,200 ml
Recommended for applications which require average speed For mixing tasks with little or average viscosity Blade size, 70 x 70mm Material – stainless steel Length – 450mm Shaft diameter – 8mm Max rpm – 800
Due to its blade dimensions, the square-blade impeller BR 13 is ideal for loosening and homogenizing in vessels with the following characteristics:
ideal vessel diameter: 140 mm ideal ground clearance: 7 mm ideal filling level: 140 mm ideal volume: 2,200 ml
Recommended for applications which require average speed For mixing tasks with little or average viscosity Blade size, 70 x 70mm Material – stainless steel Length – 450mm Shaft diameter – 8mm Max rpm – 800
Additional Information
| Brand | Heidolph North America |
|---|---|
| UNSPSC | 41103810 |
