Quick Overview
Heating-up time to 37 °C [min]: 42
Recovery time after 30 seconds door open at 37 °C [min]: 15
Temperature fluctuation at 37 °C [± K]: 0.1
Temperature range +5 °C above ambient temperature to [°C]: 100
Temperature variation at 37 °C [± K]: 0.3
Details
Benefits
Excellent temporal and spatial temperature accuracy
High process reliability
100 °C disinfection routine
Important characteristics
Temperature range: ambient temperature plus 5 °C to 100 °C
High temperature accuracy thanks to APT.line™ technology
Gravity convection
Controller with LCD display
Electromechanical control of the exhaust air flap
Inner door made of tempered safety glass
2 chrome-plated racks
Units up to 115 L are stackable
Class 3.1 integrated independent temperature safety device (DIN 12880) with visual alarm
Ergonomic handle design
USB port for recording data
Technical specifications
Performance Data Temperature:
Heating-up time to 37 °C [min]: 42
Recovery time after 30 seconds door open at 37 °C [min]: 15
Temperature fluctuation at 37 °C [± K]: 0.1
Temperature range +5 °C above ambient temperature to [°C]: 100
Temperature variation at 37 °C [± K]: 0.3
Electrical data
Nominal power [kW]: 0.3
Phase (Nominal voltage)L 1~
Power frequency [Hz]: 60
Rated Voltage [V]: 120
Unit fuse [A]: 12.5
Doors
Unit doors: 1
Housing dimensions not incl. fittings and connections
Depth net [in]: 22.26
Height net [in]: 24.63
Width net [in]: 22.06
Internal Dimensions
Depth [in]:14.97
Height [in]: 16.55
Width [in]: 14.18
Measures
Interior volume [cu.ft.]: 2
Load per rack [lbs]: 66
Net weight of the unit (empty) [lbs]: 88
Permitted load [lbs]: 154
Wall clearance back [in]: 6.3
Wall clearance sidewise [in]: 3.94
Environment-specific data
Energy consumption at 37 °C [Wh/h]: 25
Fixtures
Number of shelves (std./max.): 2/4
