Quick Overview
Recovery time after 30 seconds door open at 37 °C [min]: 8
Temperature fluctuation at 37 °C [± K]: 0.1
Temperature range +6 °C above ambient temperature to: 50 °C
Temperature variation at 37 °C [± K]: 0.4
Details
Benefits
Safe – cell cultures receive maximum protection against contamination
Reliable – constant well-being conditions for the cells
Smart – simple routine cleaning and convenient operation
Economical – efficient operation without consumables
Important characteristics
Temperature range: +6 °C above ambient temperature to +50 °C
Humidity range: 90 to 95% RH
CO₂ control range: 0 to 20 vol.% CO₂
Tried-and-tested anti-contamination concept with 180 °C hot air sterilization
Humidification system with condensation protection
CO₂ gas mixing jet with Venturi effect
CO₂ sensor with infrared technology
LCD to display temperature and CO₂ along with additional information and alarms
Internal data logger, measured values can be read out in open format via USB
Tightly fitted inner door made of safety glass
Seamless stainless steel inner chamber
Perforated shelves, stainless steel
Troubleshooting system with visual and acoustic alarms
Interfaces: Ethernet, USB, zero-voltage alarm contact
Units can be stacked with stacking adapters; the CB-S is suitable for stacking with CB and CBF models of the same size
Optional equipment
Copper interior fittings consisting of copper shelves and copper-plated water pan
Stacking adapter for secure, space-saving installation
CO₂ gas tank changer for connecting two gas tanks to one or two incubators
CO₂ shaker with corrosion-resistant components in a stainless-steel housing
APT-COM Multi Management Software – for managing, recording, and documenting unit parameters
Services – wide range of services to ensure that the unit functions correctly
Performance Data Temperature
Recovery time after 30 seconds door open at 37 °C [min]: 8
Temperature fluctuation at 37 °C [± K]: 0.1
Temperature range +6 °C above ambient temperature to: 50 °C
Temperature variation at 37 °C [± K]: 0.4
Performance Data Climate
Humidity range: 90…95
CO₂-Data
CO₂ measurement IR
CO₂ range [Vol.-% CO₂]: 0…20
CO₂ Recovery time after 30 seconds door open at 5 Vol.-% CO₂ [min]: 5
Electrical data
Nominal power [kW]: 1.5
Phase (Nominal voltage): 1~
Power frequency [Hz]: 50/60
Rated Voltage [V]: 100…120
Unit fuse [A]: 16
Doors
Inner doors: 1
Unit doors: 1
Housing dimensions not incl. fittings and connections
Depth net [in]: 30.93
Height net [in]: 40.2
Width net [in]: 29.16
Internal Dimensions
Depth [in]: 22.65
Height [in]: 29.55
Width [in]: 24.43
Measures
Interior volume [cu.ft.]: 9.4
Load per rack [lbs]: 22
Net weight of the unit (empty) [lbs]: 269
Permitted load [lbs]: 88
Wall clearance back [in]: 3.94
Wall clearance sidewise [in]: 1.97
Environment-specific data
Energy consumption at 37 °C [Wh/h]: 55
Sound-pressure level [dB(A)]: 41
Fixtures
Number of shelves (std./max.): 2/8
Additional Information
