Functions
Environmentally-friendly, economic cooling solution
High efficiency
Precise temperature control
Powerful circulation pump
Intelligent energy management
Reliable continuously operation with warning functions
Pilot ONE controller with 5.7" touchscreen
Digital filling level indicator
2 x USB (Host and Device), Ethernet and RS232 interfaces
Heater options available
Technical specifications
General information & temperature controller
Temperature range: -20...40 °C
Temperature stability: ±0.5 °C
Controller: Pilot ONE (E-grade "Basic")
Safety class: I / NFL
Protection class: IP20
Dimensions (W x D x H): 400 x 440 x 1230 mm | 15.75 x 17.32 x 48.43 inches
Weight: 132 kg | 291.06 pounds
Heating / cooling capacity
Cooling capacity:
15: 0: -10: -20: °C
2: 2: 1,5: 0,8: kW
Cooling machine: water-cooled
Refrigerant (ASHRAE, GHS): R507 (A1, H280) (0,54 kg)
Circulation pump
Pressure pump max.: 30 lpm ; 3.8 bar | 7.93 gpm ; 55.1 psi
Pump connection: G3/4 AG male
Connections
Pt100 connection: Pt100
Digital interface: RS232, Ethernet, USB Device, USB Host
Operating data
Permissible ambient temp.: 5...40 °C
Filling volume min.: 2.5 Liters | 0.66 gal
Volume of expansion: 4 Liters | 1.06 gal
Cooling water connection: G1/2 AG
Cooling water differential pressure min.: 1 bar | 14.5 psi
Cooling water pressure max.: 6 bar | 87 psi
Power supply: 208V 2~ 60Hz
Current max.: 8 A
