Quick Overview
Lowest energy consumption in its class
Environmentally-friendly refrigerants R-290 and R-170
Thermal insulation with unique long-life VIPs (vacuum insulation panels)
Rust-proof interior made completely of stainless steel
Environmentally-friendly refrigerants R-290 and R-170
Thermal insulation with unique long-life VIPs (vacuum insulation panels)
Rust-proof interior made completely of stainless steel
Details
Range of temperature controller: -90 °C to -40 °C
Cooling down time from 22 °C to -80 °C [min]: 360
Temperature fluctuation at -80 °C [± K]: 1.5
Temperature variation at -80 °C [± K]: 2.5
Warm-up time during power failure from -80 °C / -122 °F to -60 °C / -76 °F [min]: 230
Nominal power [kW]: 1.4
Phase (Nominal voltage): 1~
Power frequency [Hz]: 60
Rated Voltage [V]: 120
Unit fuse [A]: 13
Unit doors: 1
Housing dimensions not incl. fittings and connections: Depth 36.96 in, Height 77.50 in, Width 3254 in
Internal Dimensions:Depth 23.84 in, Height 51.2 in, Width 23.88 in
Interior volume [cu.ft.]: 16.8
Net weight of the unit (empty) [lbs]: 545
Permitted load [lbs]: 441
Permitted load of individual compartment [lbs]: 110
Wall clearance back [in]: 3.94
Wall clearance sidewise [in]: 9.85
Average heat dissipation at set-point -80 °C and ambient temperature = 21 °C [W]: 330
Energy consumption at set-point -80 °C and ambient temperature = 21 °C [kWh/d]: 7.9
Sound-pressure level [dB(A)]: 47
Number of shelves (std./max.): 3/13
Cryoboxes, 50 mm: 352
Freezer racks per compartment: 4
Additional Information
| Brand | No |
|---|---|
| UNSPSC | 41103005 |
