Quick Overview
Maximum Capacity: 500 lb (250 kg)
Readability: 0.02 lb (10 g)
Platform Size: 24 in x 18 in (610 mm x 457 mm)
Construction
304-grade stainless steel platform, sand grey powder-coated steel frame, aluminum load cell, non-slip adjustable rubber feet, level indicator
Design Features
150% capacity overload protection
Readability: 0.02 lb (10 g)
Platform Size: 24 in x 18 in (610 mm x 457 mm)
Construction
304-grade stainless steel platform, sand grey powder-coated steel frame, aluminum load cell, non-slip adjustable rubber feet, level indicator
Design Features
150% capacity overload protection
Details
The OHAUS next generation Defender 5000 R Series base offers durability for the most demanding of industrial applications. The R series features moisture-protected single-point load cells, powder-coated steel construction, non-slip rubber adjustable feet, removable stainless steel weighing pans and integrated leveling bubbles. Maximum non-approved resolution of 1:15,000d meets the needs of industrial weighing applications that require extreme accuracy.
Maximum Capacity: 500 lb (250 kg)
Readability: 0.02 lb (10 g)
Platform Size: 24 in x 18 in (610 mm x 457 mm)
Protection Rating: IP67
Dimensions: 24.5 in x 5.1 in x 18 in (633 mm x 130 mm x 457 mm) (LxHxW)
Net Weight: 48.5 lb (22 kg)
Platform Construction: Stainless Steel
Working Environment: 14°F – 104°F, 80%RH, non-condensing (-10°C – 40°C, 80%RH, non-condensing)
Maximum Capacity: 500 lb (250 kg)
Readability: 0.02 lb (10 g)
Platform Size: 24 in x 18 in (610 mm x 457 mm)
Protection Rating: IP67
Dimensions: 24.5 in x 5.1 in x 18 in (633 mm x 130 mm x 457 mm) (LxHxW)
Net Weight: 48.5 lb (22 kg)
Platform Construction: Stainless Steel
Working Environment: 14°F – 104°F, 80%RH, non-condensing (-10°C – 40°C, 80%RH, non-condensing)
Additional Information
| Brand | Ohaus |
|---|---|
| UNSPSC | 41111509 |
