Ohaus FC5718 Frontier 5000 Series Multi Pro High Speed Centrifuge, 18000 RPM, 30314813 Centrifuge Bundle Savings at Sycamore Life Sciences

Description

As an air-cooled model, the FC5718 is a versatile essential for any lab environment.

The Frontier 5000 line delivers the precision, build quality, and service longevity that research and clinical laboratories depend on.

Frontier 5000 Multi Pro Centrifuges are designed for universal use in research, industrial & clinical laboratories. The FC5718 model provides a high-speed centrifugation platform that can be customized to fit workflow needs using a wide variety of rotors and accessories.

Featuring high-speed performance at maximum volume, automatic rotor identification, and a maintenance-free induction drive—these multi-purpose centrifuges are a must for any lab. This Powerful and Versatile Universal Centrifuge features a corrosion-resistant stainless steel chamber with Polycarbonate/ABS plastic lid and Backlit Liquid Crystal Display (LCD).

Centrifugal Separation and General Sample Preparation

Cell Pelleting and Protein Separation

Nucleic Acid Separation and Cell Concentrating

Chemical Separation and Diagnostics

Environmental Sample Preparation and Blood Sample Processing

Choosing the Right Model

The Frontier series offers four distinct designs: Multi Pro, Multi, Micro, and Mini. The FC5718 is a high-performance Multi Pro benchtop model, offering superior speed (up to 18,000 rpm) and versatile application support compared to standard multi-purpose units.

Size and Application

The FC5718 is an air-cooled unit ideal for standard lab applications where high RCF is required but temperature control below ambient is not a necessity.

Rotor Selection

To simplify the selection process, Ohaus provides a comprehensive Frontier 5000 rotor guide. This guide is an invaluable tool for identifying the appropriate model for your specific requirements and selecting the right rotor package for your applications, supporting everything from 0.2 ml to 100 ml tubes.

Making Your Decision

Assess your laboratory's specific volume and high-speed RCF needs.

Consult the Frontier 5000 rotor guide for accessory compatibility.

Compare the features of this air-cooled model against refrigerated versions (FC5718R) if samples are temperature-sensitive.

Consider future requirements to ensure long-term utility.

Product Specifications

Speed Range 200 rpm – 18,000 rpm

Maximum Relative Centrifugal Force 23,542 x g

Maximum Capacity (Rotor) 4 x 100 ml

Running Time Quickspin; 10 sec to 99 h 59 min 59 sec; Continuous

Safety Certification CE; FCC

Working Environment 36°F – 95°F, 80% RH, non-condensing (2°C – 35°C)

Program Memories 99

Acceleration/Deceleration Gear 10 / 10

Dimensions (L x H x W) 19.65 in x 13.82 in x 16.06 in (499 mm x 351 mm x 408 mm)

Net Weight 95 lb (43 kg)

Noise Level ≤60±2 dB(A)

Power / Consumption 120V AC Power (Included) / 455 W

Rotor Compatibility

Swing out 4 x 100 ml ID

Swing out 4 x 100 ml ID (Sealable)

Swing out 2 x 3MTP ID

Angle 6 x 85 ml RB ID Hi

Angle 6 x 85 ml RB ID

Angle 4 x 85 ml RB ID Hi

Angle 10 x 50 ml FA ID

Angle 6 x 50 ml RB ID Hi

Angle 6 x 50 ml RB/FA ID

Angle 30 x 15 ml RB/FA ID

Angle 20 x 10 ml RB ID Hi

Angle 12 x 15 ml RB/FA ID

Angle 44 x 1.5 / 2.0 ml ID

Angle 30 x 1.5 / 2.0 ml ID (Sealable)

Angle 24 x 1.5 / 2.0 ml ID (Sealable)

Angle 24 x 1.5 / 2.0 ml ID

Angle 12 x 1.5 / 2.0 ml ID

Angle 64 x 0.5 ml ID

Angle 4 x 8-w PCR Strip ID

Rotor Recognition Method Auto-ID

Product Specifications
Speed Range	200 rpm – 18,000 rpm
Maximum Relative Centrifugal Force	23,542 x g
Maximum Capacity (Rotor)	4 x 100 ml
Running Time	Quickspin; 10 sec to 99 h 59 min 59 sec; Continuous
Safety Certification	CE; FCC
Working Environment	36°F – 95°F, 80% RH, non-condensing (2°C – 35°C)
Program Memories	99
Acceleration/Deceleration Gear	10 / 10
Dimensions (L x H x W)	19.65 in x 13.82 in x 16.06 in (499 mm x 351 mm x 408 mm)
Net Weight	95 lb (43 kg)
Noise Level	≤60±2 dB(A)
Power / Consumption	120V AC Power (Included) / 455 W
Rotor Compatibility	Swing out 4 x 100 ml ID Swing out 4 x 100 ml ID (Sealable) Swing out 2 x 3MTP ID Angle 6 x 85 ml RB ID Hi Angle 6 x 85 ml RB ID Angle 4 x 85 ml RB ID Hi Angle 10 x 50 ml FA ID Angle 6 x 50 ml RB ID Hi Angle 6 x 50 ml RB/FA ID Angle 30 x 15 ml RB/FA ID Angle 20 x 10 ml RB ID Hi Angle 12 x 15 ml RB/FA ID Angle 44 x 1.5 / 2.0 ml ID Angle 30 x 1.5 / 2.0 ml ID (Sealable) Angle 24 x 1.5 / 2.0 ml ID (Sealable) Angle 24 x 1.5 / 2.0 ml ID Angle 12 x 1.5 / 2.0 ml ID Angle 64 x 0.5 ml ID Angle 4 x 8-w PCR Strip ID
Rotor Recognition Method	Auto-ID

Specifications

More Information
Brand	Ohaus
UNSPSC	41103909
Centrifuge Type	High Speed Centrifuge
Dimensions	13.82 in x 19.65 in x 16.06 in, 351 mm x 499 mm x 408 mm
Maximum RCF x g	23542 x g
Maximum RPM	18000 RPM
Minimum RPM	200 RPM
Rotor Capacity	100 mL
Rotor Places	4
Rotor Type	Angle Rotor, Sing Out Rotor
